Hello,
I am using MikoPBX ver: 2024.1.114 (latest as of today to my knowledge).
I have two trunks up and running (they both are green). There is no problem receiving calls. Call groups and such are working OK.
This is a migration from 3CX to MikoPBX and so I believe service provider settings are OK.
However, I cannot start outgoing calls. They always fail with “busy” message.
Below is one call log. I have no such technical detail to understand these logs. Can anybody help me to figure out what is the problem? One thing I cannot be sure is I do not know if system is choosing the correct trunk since I have two of them for different purposes. I couldn’t find any information to identify at the log level which trunk definition is which.
Here is the call log
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:1] ExecIf("PJSIP/1020-00000003", "0?Wait(0.2)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:2] ExecIf("PJSIP/1020-00000003", "0?ChannelRedirect(,all_peers,,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:3] ExecIf("PJSIP/1020-00000003", "0?Set(EXPORT(,__ORIG_CALLID)=[C-00000003])") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:4] ExecIf("PJSIP/1020-00000003", "0?Hangup()") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:5] Set("PJSIP/1020-00000003", "cleanNumber=+447864530566") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:6] ExecIf("PJSIP/1020-00000003", "0?Goto(all_peers,+447864530566,7)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:7] Set("PJSIP/1020-00000003", "__FROM_CHAN=PJSIP/1020-00000003") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:8] Set("PJSIP/1020-00000003", "__M_CALLID=[C-00000003]") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:9] ExecIf("PJSIP/1020-00000003", "1?Set(__OLD_LINKEDID=mikopbx-1767688821.7)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:10] ExecIf("PJSIP/1020-00000003", "1?Gosub(set_from_peer,s,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [s@set_from_peer:1] NoOp("PJSIP/1020-00000003", "__FROM_PEER set to 1020")
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [s@set_from_peer:1] return("PJSIP/1020-00000003", "")
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:11] ExecIf("PJSIP/1020-00000003", "0?Gosub(set_orign_chan,s,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:12] ExecIf("PJSIP/1020-00000003", "0?Set(CALLERID(num)=1020)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:13] ExecIf("PJSIP/1020-00000003", "0?Set(CALLERID(name)=1020)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:14] ExecIf("PJSIP/1020-00000003", "0?Set(__FROM_PEER=1020)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:15] Set("PJSIP/1020-00000003", "CHANNEL(hangup_handler_wipe)=hangup_handler,s,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:16] Gosub("PJSIP/1020-00000003", "dial,+447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [+447864530566@dial:1] CELGenUserEvent("PJSIP/1020-00000003", "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")
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [+447864530566@dial:1] UserEvent("PJSIP/1020-00000003", "CdrConnector,AgiData: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")
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [+447864530566@dial:1] return("PJSIP/1020-00000003", "")
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:17] GosubIf("PJSIP/1020-00000003", "0?all_peers-custom,+447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:18] GosubIf("PJSIP/1020-00000003", "0?applications,+447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:19] GosubIf("PJSIP/1020-00000003", "0?internal,+447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@all_peers:20] GosubIf("PJSIP/1020-00000003", "1?outgoing,+447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@outgoing:1] NoOp("PJSIP/1020-00000003", "Strip + sign from number") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [+447864530566@outgoing:2] Goto("PJSIP/1020-00000003", "outgoing,447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx_builtins.c: Goto (outgoing,447864530566,1)
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:1] Ringing("PJSIP/1020-00000003", "") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:2] Set("PJSIP/1020-00000003", "src_number=447864530566") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:3] GosubIf("PJSIP/1020-00000003", "0?outgoing-custom,447864530566,1") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:4] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-C642ED59-23-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:5] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-C642ED59-24-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:6] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-C642ED59-25-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:7] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-7958C6AB-26-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:8] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-7958C6AB-27-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:9] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-C642ED59-28-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:10] ExecIf("PJSIP/1020-00000003", "0?Gosub(SIP-TRUNK-C642ED59-29-outgoing,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:11] ExecIf("PJSIP/1020-00000003", "0?Hangup()") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:12] ExecIf("PJSIP/1020-00000003", "0?Gosub(transfer_dial_hangup,447864530566,1)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:13] ExecIf("PJSIP/1020-00000003", "0?AGI(check_redirect.php,)") in new stack
[2026-01-06 11:40:21] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:14] ExecIf("PJSIP/1020-00000003", "1?Gosub(dial,447864530566,1)") in new stack
[2026-01-06 11:40:22] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [447864530566@dial:1] return("PJSIP/1020-00000003", "")
[2026-01-06 11:40:22] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:15] Playback("PJSIP/1020-00000003", "silence/2,noanswer") in new stack
[2026-01-06 11:40:22] VERBOSE[22232][C-00000003] file.c: <PJSIP/1020-00000003> Playing 'silence/2.gsm' (language 'tr-tr')
[2026-01-06 11:40:24] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:16] ExecIf("PJSIP/1020-00000003", "0?Playback(followme/sorry,noanswer):Playback(cannot-complete-as-dialed,noanswer)") in new stack
[2026-01-06 11:40:24] VERBOSE[22232][C-00000003] file.c: <PJSIP/1020-00000003> Playing 'cannot-complete-as-dialed.gsm' (language 'tr-tr')
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Executing [447864530566@outgoing:17] Hangup("PJSIP/1020-00000003", "") in new stack
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Spawn extension (outgoing, 447864530566, 17) exited non-zero on 'PJSIP/1020-00000003'
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Executing [h@outgoing:1] ExecIf("PJSIP/1020-00000003", "0?Goto(transfer_dial_hangup,h,1)") in new stack
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] app_stack.c: PJSIP/1020-00000003 Internal Gosub(hangup_handler,s,1) start
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Executing [s@hangup_handler:1] NoOp("PJSIP/1020-00000003", "--- hangup - PJSIP/1020-00000003 ---") in new stack
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Executing [s@hangup_handler:2] Gosub("PJSIP/1020-00000003", "hangup_chan,s,1") in new stack
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [s@hangup_chan:1] CELGenUserEvent("PJSIP/1020-00000003", "eyJPTERfTElOS0VESUQiOiJtaWtvcGJ4LTE3Njc2ODg4MjEuNyIsIlVOSVFVRUlEIjoibWlrb3BieC0xNzY3Njg4ODIxLjdfNnc0NFZiIiwiVk1TVEFUVVMiOiIiLCJhY3Rpb24iOiJoYW5ndXBfY2hhbiIsImFnaV9jaGFubmVsIjoiUEpTSVAvMTAyMC0wMDAwMDAwMyIsImFnaV90aHJlYWRpZCI6Im1pa29wYngtMTc2NzY4ODgyMS43Xzc3T0VEOCIsImRpYWxzdGF0dXMiOiIiLCJkaWQiOiIiLCJlbmQiOiIyMDI2LTAxLTA2IDExOjQwOjI1LjM5MSIsImxpbmtlZGlkIjoibWlrb3BieC0xNzY3Njg4ODIxLjciLCJzcmNfbnVtIjoiMTAyMCIsInZlcmJvc2VfY2FsbF9pZCI6IltDLTAwMDAwMDAzXSJ9")
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [s@hangup_chan:1] UserEvent("PJSIP/1020-00000003", "CdrConnector,AgiData:eyJPTERfTElOS0VESUQiOiJtaWtvcGJ4LTE3Njc2ODg4MjEuNyIsIlVOSVFVRUlEIjoibWlrb3BieC0xNzY3Njg4ODIxLjdfNnc0NFZiIiwiVk1TVEFUVVMiOiIiLCJhY3Rpb24iOiJoYW5ndXBfY2hhbiIsImFnaV9jaGFubmVsIjoiUEpTSVAvMTAyMC0wMDAwMDAwMyIsImFnaV90aHJlYWRpZCI6Im1pa29wYngtMTc2NzY4ODgyMS43Xzc3T0VEOCIsImRpYWxzdGF0dXMiOiIiLCJkaWQiOiIiLCJlbmQiOiIyMDI2LTAxLTA2IDExOjQwOjI1LjM5MSIsImxpbmtlZGlkIjoibWlrb3BieC0xNzY3Njg4ODIxLjciLCJzcmNfbnVtIjoiMTAyMCIsInZlcmJvc2VfY2FsbF9pZCI6IltDLTAwMDAwMDAzXSJ9")
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx_lua.c: Executing [s@hangup_chan:1] return("PJSIP/1020-00000003", "")
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] pbx.c: Executing [s@hangup_handler:3] Return("PJSIP/1020-00000003", "") in new stack
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] app_stack.c: Spawn extension (outgoing, h, 2) exited non-zero on 'PJSIP/1020-00000003'
[2026-01-06 11:40:25] VERBOSE[22232][C-00000003] app_stack.c: PJSIP/1020-00000003 Internal Gosub(hangup_handler,s,1) complete GOSUB_RETVAL=
Any help is very much appreciated.
Thanks & Regards,
Ertan
